m8 cable
Description
Item name: M8 cable
Number of contacts: 3,4,6,8
Connector locking system:screw
Termination:solder
Wire guage:AWG26/AWG24
Degree of protection:IP67
Mechanical operation:>100 mating cycles
Upper temperature:+80℃
Lower temperature:-25℃
Rated voltage:60V,30V,30V,30V
Rated current:4A,4A,1.5A,1.5A
Rated impulse voltage:800V
Pollution degree:3
Contact resistance:≤3mΩ
Material of contact:Brass
Contact plating:Gold
Material of contact body:PA
Material of housing:Brass nickel plated
Metric M8 connectors are for small sensors and actuators.The waterproof rating is IP67,these are ideally suited for industrial control networks where small sensors are required.
