m23 cable
Description
Item name:m23 cable
Number of contacts:6,9,12,16,19
Connector locking system:screw
Termination:solder
Degree of protection:IP67
Mechanical operation:>500 mating cycles
Upper temperature:+125℃
Lower temperature:-25℃
Rated voltage:300V
Rated impulse voltage:2500V
Contact resistance:≤3mΩ
Material of contact:Brass
Contact plating:Gold
Material of contact body:PBT/PA66
Material of housing:Brass nickel plated
